SL08NC01

Product Model

SL08NC01

Add List

Product parameters


DETAIL:

The  Standing Server Cabinet Is A Cost Effective Cabinet That Can Be Installed In Equipment Rooms Or In Office Environments Where Aesthetics Are Important .The Frame Made From Comes With Steel Side, Top And Rear Door Plus A Toughened Glass Front Door, Two Pairs Of Shelf Rails Are Provided For Mounting Shelves And Other Accessories In The 600mm\800mm And 960mm Deep Cabinets. 19" Telecommunication And Data Racks Designed For Installing Patch Panels, Active Components For Lan Construction, Modems, Industry-Controlling Devices, Stage Lighting Control, Monitor Equipments Etc. Unassembled Rack Is Equipped With 2 Pairs Of 19" Movable Vertical Extrusions, One Pair Of Side Panels With Quick Release Locking Fastener, Tempered Glass Front Door With Lock, Rear Metal Door With Lock. Increase Operation Reliability For Inside Equipments, Strong Structure With Maximum Static Load Of 500 Kg Up. Several Lockable Cable Entrance On The Top/Bottom Plate.



FEATURES:

       1. Range Of Medium Duty Cabinets Of Durable Modular Construction

       2. With Tempered Glass Locking Doors section doors, Enable ventilation and reliable operation

       3. Lockable removable side panels

       4. Several lockable wiring holes on Top/Botto, Size of the large hole at the bottom adjustable

       5. The frame can bemoved according to requirement, U was marked in the frame to identify the height

       6. Bottom base can fix the cabinet, Cable entry, Airflow, Avoiding arts

       7. Can be customized to individual requirements, Without doors, Sides And/Or the top panel

       8. Earthing screw

       9. Adjustable angles

       10. Cabinets are vented to allow cooling

       11. Standard colour is computer grey

       12. No tools are required to change the door from left hand to right hand opening


Cabinet Size

Width×Depth×Height

47U  Data Cabinet

600×600×2200 mm

47U  Data Cabinet

600×800×2200 mm

47U  Data Cabinet

600×960×2200 mm

47U  Data Cabinet

800×800×2200 mm

47U  Data Cabinet

800×960×2200 mm

42U  Data Cabinet

600×600×2000 mm

42U  Data Cabinet

600×800×2000 mm

42U  Data Cabinet

600×960×2000 mm

42U  Data Cabinet

800×800×2000 mm

42U  Data Cabinet

800×960×2000 mm

37U  Data Cabinet

600×600×1800 mm

37U  Data Cabinet

600×800×1800 mm

37U  Data Cabinet

600×960×1800 mm

32U  Data Cabinet

600×600×1600 mm

32U  Data Cabinet

600×800×1600 mm

27U  Data Cabinet

600×600×1400 mm

27U  Data Cabinet

600×800×1400 mm

22U  Data Cabinet

600×600×1200 mm

22U  Data Cabinet

600×800×1200 mm

Ordering Information


Product Code

Description

Packaging

GW

SL08NC01

Network Cabinet

1PCS

--
