Product Model
SFP-S31101 SFP-S61101 SFP-SA1101
Product parameters
NOTES:
ELECTRICAL:
1. Voltage rating: 125 VAC RMS
2. Current rating: 1.5 AMP
3. Contact resistance: 20 Milliohms MAX
4. Insulation resistance: 100 Megohms MIN @ 500 VDC
5. Dielectric strength: 750 VAC RMS 60Hz, 1MIN
MECHANICAL：
1. Cover material: ABS
2. Base material: ABS
3. IDC material: PC UL94V-0 CONTACT; PHOSPHOR BRONZE, TIN PLATED
4. PCB material: FR-4 T=1.6mm
5. RJ45 JACK LIFE: 750 CYCLES MIN
6. IDC LIFE: 200 TIMES MIN
7. WIRE: AWG 22-24
9. TIA CAT5e PERM.LINK TEST: WORST PAIR NEXT MARGIN ≥5.0dB
10. Retentiveness of insertion structure: 50N 60±5s
ENVIRONMENTAL：
1. Storage: -40°TO +70°
2. Operation: -10°TO +60°
Mates with modular plug conforming to FCC part 68, Subpart F.
Ordering Information
Product Code | Description | Packaging | Carton Size | GW |
SFP-S31101 | Cat.5e Mounting box, 1port RJ45 | 350 PCS | 42*41*53 cm | 13.6 kg |
SFP-S61101 | Cat.6 Mounting box, 1port RJ45 | 350 PCS | 42*41*53 cm | 13.6 kg |
SFP-SA1101 | Cat.6A Mounting box, 1port RJ45 | 350 PCS | 42*41*53 cm | 13.6 kg |
