Product Model
SWB-225601
SWB-225601 : Wiring Blocks ,100 Pair, Without Legs ,without connection
![](/static/home/images/icon-4.png)
Product parameters
ELECTRICAL:
1. VOLTAGE RATING: 125 VAC RMS
2. CURRENT RATING: 1.5 AMP
3. CONTACT RESISTANCE: 100 MILLIOHMS MAX
4. INSULATION RESISTANCE: 1000 MEGOHMS MIN @ 500 VDC
5. DIELECTRIC STRENGTH: 750 VAC RMS 60HZ, 1MIN
MECHANICAL:
1. BASE MATERIAL: PC UL94V-0
2. CABLE BINDER MATERIAL: PC UL94V-0
3. IDC HOUSING AND PLATE: PC UL94V-0
4. TERMINALS MATERIAL: PHOSPHOR BRONZE T=0.8mm
5. WIRE: AWG 24~26
Ordering Information
Product Code | Description | Packaging | Carton Size | GW |
SWB-225601 | Wiring Blocks ,100 Pair, Without Legs ,without connection | -- | -- | -- |
