![50D1](http://sur-link.com/upload/images/product/20231208/17020041281314947.png)
Product Model
SWB-114601
SWB-114601 : Wiring Blocks ,50 Pair, With Legs ,with connection Blocks
![](/static/home/images/icon-4.png)
Product parameters
ELECTRICAL:
1. VOLTAGE RATING: 125 VAC RMS
2. CURRENT RATING: 1.5 AMP
3. CONTACT RESISTANCE: 100 MILLIOHMS MAX
4. INSULATION RESISTANCE: 1000 MEGOHMS MIN @ 500 VDC
5. DIELECTRIC STRENGTH: 750 VAC RMS 60HZ, 1MIN
MECHANICAL:
1. BASE MATERIAL: PC UL94V-0
2. CABLE BINDER MATERIAL: PC UL94V-0
3. LEG MATERIAL: PC UL94V-0
4. IDC HOUSING AND PLATE: PC UL94V-0
5. TERMINALS MATERIAL: PHOSPHOR BRONZE T=0.8mm
6. WIRE: AWG 24~26
Ordering Information
Product Code | Description | Packaging | Carton Size | GW |
SWB-114601 | Wiring Blocks ,50 Pair, With Legs ,with connection Blocks | 40 PCS | 40*29*53 cm | 10.1 kg |
