Product Model
SPP-2C92B1 SPP-2C92A1 SPP-2992B1 SPP-2992C1 SPP-2992A1 SPP-2692D1 SPP-2692L1 SPP-2692H1
Product parameters
NOTES:
ELECTRICAL :
1. VOLTAGE RATING：125 VAC RMS.
2.CURRENT RATING ：1.5 AMP
3. CONTACT RESISTANCE ：20 MILLIOHMS MAX.
4. INSUL ATION RESISTANCE ：100 MEGOHMS MIN @ 500 VDC.
5. DIELECTRIC STRENGTH：750 VAC RMS 60Hz， 1MIN.
6. C6a PERMANENT LINK :CONFORM TO ANSI/TIA/EIA-568 B.2- 1
MECHANICAL:
1. HOUSING MATERIAL：PBT+ 30%GF UL 94V
2. PANEL FRAME：S45C,POWDER COATING IN BL ACK COL OR
3 IDCMATERI：PC UL94V-0 CON TACT: PHOSPHOR BRONZE ,TIN PL ATED
4. RJ45 JACKLFE ：750 CYCLES MIN
5. IDC UIFE：200 TIMES MIN
6. WIRE：AWG 24- 26
7. TIA CAT6o PERM.LINK TEST: WORST PAIR NEXT MARGIN 23. OdB
8. RE TENTIVENESS OF INSERTION STRUCTURE : 50N 60+5 S
ENVIRONMENTAL:
1. STORAGE：-40°C TO + 70"C.
2. OPERATION : -10C TO +60C.
MATES WITH MODUL AR PLUG CONFORMING TO FCC PART 68，SUBPART F
Ordering Information
Product Code | Description | Packaging | Carton Size | GW |
SPP-2692H1 | UTP Cat.5e Patch Panel , 48 Port, 110 IDC, with back bar | 10 PCS | 53*32*32 cm | 15 kg |
SPP-2692L1 | UTP Cat.5e Patch Panel , 48 Port, LSA IDC, with back bar | 10 PCS | 53*32*32 cm | 15 kg |
SPP-2692D1 | UTP Cat.5e Patch Panel , 48 Port, Dual USE IDC, with back bar | 10 PCS | 53*32*32 cm | 15 kg |
SPP-2992A1 | UTP Cat.6 Patch Panel , 48 Port, 110 IDC, with back bar | 10 PCS | 53*32*32 cm | 15 kg |
SPP-2992C1 | UTP Cat.6 Patch Panel , 48 Port, LSA IDC, with back bar | 10 PCS | 53*32*32 cm | 15 kg |
SPP-2992B1 | UTP Cat.6 Patch Panel , 48 Port, Dual USE IDC, with back bar | 10 PCS | 53*32*32 cm | 15 kg |
SPP-2C92A1 | UTP Cat.6A Patch Panel, 48 Port 110 IDC | 10 PCS | 53*32*32 cm | 15 kg |
SPP-2C92B1 | UTP Cat.6A Patch Panel , 48 Port, Dual USE IDC | 10 PCS | 53*32*32 cm | 15 kg |
