Product Model
SPP-SC62D1 SPP-SC62L1 SPP-SC62H1 SPP-S962D1 SPP-S962L1 SPP-S962H1 SPP-S662D1 SPP-S662L1 SPP-S662H1
Product parameters
NOTES:
ELECTRICAL :
1. VOLTAGE RATING：125 VAC RMS.
2.CURRENT RATING ：1.5 AMP
3. CONTACT RESISTANCE：20 MILLIOHMS MAX.
4. INSUL ATION RESISTANCE：100 MEGOHMS MIN @ 500 VDC.
5. DIELECTRIC STRENGTH：750 VAC RMS 60Hz， 1MIN.
6. C6a PERMANENT LINK:CONFORM TO ANSI/TIA/EIA-568 B.2- 1
MECHANICAL:
1. HOUSING MATERIAL：PBT+ 30%GF UL 94V
2. PANEL FRAME：S45C,POWDER COATING IN BL ACK COL OR
3 IDCMATERI：PC UL94V-0 CON TACT: PHOSPHOR BRONZE ,TIN PL ATED
4. RJ45 JACKLFE ：750 CYCLES MIN
5. IDC UIFE ; 200 TIMES MIN
6. WIRE：AWG 22- 24
7. TIA CAT6o PERM.LINK TEST: WORST PAIR NEXT MARGIN 23. OdB
8. RE TENTIVENESS OF INSERTION STRUCTURE : 50N 60+5 S
ENVIRONMENTAL:
1. STORAGE：-40°C TO + 70"C.
2. OPERATION : -10C TO +60C.
MATES WITH MODUL AR PLUG CONFORMING TO FCC PART 68，SUBPART F
Ordering Information
Product Code | Description | Packaging | Carton Size | GW |
SPP-S662H1 | UTP Cat.5e Patch Panel , 24 Port, 110 IDC, with back bar | 15 PCS | 53*29*32 cm | 11.5 kg |
SPP-S662L1 | UTP Cat.5e Patch Panel , 24 Port, LSA IDC, with back bar | 15 PCS | 53*29*32 cm | 11.5 kg |
SPP-S662D1 | UTP Cat.5e Patch Panel , 24 Port, Dual USE IDC, with back bar | 15 PCS | 53*29*32 cm | 11.5 kg |
SPP-S962H1 | UTP Cat.6 Patch Panel , 24 Port, 110 IDC, with back bar | 15 PCS | 53*29*32 cm | 11.5 kg |
SPP-S962L1 | UTP Cat.6 Patch Panel , 24 Port, LSA IDC, with back bar | 15 PCS | 53*29*32 cm | 11.5 kg |
SPP-S962D1 | UTP Cat.6 Patch Panel , 24 Port, Dual USE IDC, with back bar | 15 PCS | 53*29*32 cm | 11.5 kg |
SPP-SC62H1 | UTP Cat.6A Patch Panel, 24 Port 110 or LSA IDC, with Back Bar | 15 PCS | 53*29*32 cm | 11.5 kg |
SPP-SC62L1 | UTP Cat.6A Patch Panel , 24 Port, LSA IDC, with back bar | 15 PCS | 53*29*32 cm | 11.5 kg |
SPP-SC62D1 | UTP Cat.6A Patch Panel , 24 Port, Dual USE IDC, with back bar | 15 PCS | 53*29*32 cm | 11.5 kg |
