Product Model
SPP-3A62D1 SPP-3A62H1 SPP-3A62L1
Product parameters
NOTES:
ELECTRICAL:
1. VOLTAGE RATING : 125 VAC RMS
2. CURRENT RATING : 1.5 AMP
3. CONTACT RESISTANCE : 20 MILLIOHMS MAX
4. INSULATION RESISTANCE 100 MECOHMS MIN 。500 VDC
5. DIELECTRIC STRENCTH : 750 VAC RMS 60Hz,1MIN
6.C6 PERMANENT LINK : CONFORM TO ANSI/TIA/EIA-568 B.2- 1
ENMRONMENTAL
1.STORAGE : -40”TO +70°
2. OPERATION: -10”TO +60°
RJ45 JACKS COMPLY TO REQUIREMENTS OF IEC- 60603-7-5
MATES WITH MODUL AR PL _UG CONFORMING TO FCC PART 68
MECHANICAL :
1.SHIEL D MATERIAL : BRASS C2680 T=0.25mm
2.HOUSING MATERIAL: PBT
3.CONTACT MATERIAL : PHOSPHOR BRONZE PL ATING GOLD
4.IDC MATERIAL : PC,TERMINALPHOSPHOR BRONZE.TIN PLATING
5.RJ45 JACK UFE : 750 TIMES MIN
6.IDC UFE : 200 TMES MIN
7.WIRE : AWG 22~24
8.TIA Cat 6 Perm. Link Test: Worst pair NEXT margin≥3.0dB
9.Retentiveness of insertion structure. 50N 60士5s
Ordering Information
Product Code | Description | Packaging | Carton Size | GW |
SPP-3A62H1 | FTP Cat.6 Patch Panel, 24 Port 110 IDC | 5 PCS | 55*20*27 cm | 13 kg |
SPP-3A62L1 | FTP Cat.6 Patch Panel, 24 Port, LSA IDC | 5 PCS | 55*20*27 cm | 13 kg |
SPP-3A62D1 | FTP Cat.6 Patch Panel, 24 Port, Dual Use IDC | 5 PCS | 55*20*27 cm | 13 kg |
