SPP-7133L1-1 SPP-7A32L1

SPP-7133L1-1 : FTP Ca.6A Patch panel 12Port

SPP-7A32L1 : FTP Ca.6 Patch panel 12Port

Add List

Product parameters

NOTES:

ELECTRICAL:

1. VOLTAGE RATING : 125 VAC RMS

2. CURRENT RATING : 1.5 AMP

3. CONTACT RESISTANCE : 20 MILJOHMS MAX

4. INSUL ATON RESISTANCE: 100 MEGOHMS MIN❼500 VDC

5. DIELECTRIC STRENGTH : 750 VAC RMS 60Hz,1MIN

ENMRONMENTAL:

1. STORAGE : -40”TO +70*

2. OPERATION : -10” TO +60'

CONFORM TO TIA/EIA 5688 CATEGORY 6

MATES WITH MODULAR PLUG CONFORMING T0 FCC PART 68,

MECHANICAL:

1.HOUSING MATERIAL: PBT

2.PANEL FRAME : ST12, POWDER COATING IN BL ACK CoL .OR

3.DC MATERIAL : PC TERMINAL:PHOSPHOR BRONZE.TN PL ATING

4.RJ45 JACK LIFE : 750 TIMES MIN

5.JDC LIFE : 200 TIMES MIN

6.WRE :AWG 22~26

7.TIA Cat6 Porm. Link Tost: Worst pair_ NEXT margin≥3.OdB

8.Retentiveness of insertion structure: 50N 60士59

Ordering Information
